INTR AG3000
MFG #AG3000
UPC #07827513067
SKU #4024931
249 in Stock
Stock Item
More available 09/10/2026
$111.83/EA
Product description
INTR AG3000 SINGLE PHASE SURGE PROTECTIVE DEVICE ANSI UL1449 3RD EDITION 10KA IN RATING 120/240VAC
Intermatic® Surge Protective Device, Series: AG Series, 120/240 VAC Electrical Rating, 50/60 Hz Frequency, 3 Pole, 20 kA Short Circuit, 10 kA Nominal Discharge, Modes of Protection: L-N/L-L, Green LED Indicator, 1 ph, Environmental Conditions: -13 to 140 deg F Operating Temperature, NEMA 1/2/4X Enclosure, Surface Mounting, Lead Terminal, Polycarbonate, 1/2 in H Dimensions
Intermatic® Surge Protective Device, Series: AG Series, 120/240 VAC Electrical Rating, 50/60 Hz Frequency, 3 Pole, 20 kA Short Circuit, 10 kA Nominal Discharge, Modes of Protection: L-N/L-L, Green LED Indicator, 1 ph, Environmental Conditions: -13 to 140 deg F Operating Temperature, NEMA 1/2/4X Enclosure, Surface Mounting, Lead Terminal, Polycarbonate, 1/2 in H Dimensions
- HVAC Equipment, Outdoor Irrigation Equipment, Farm Equipment, Pumps, Lighting Fixtures, Traffic Signaling Devices, HVACR Controls and Motors
- Intermatic Surge Protective Device, Series: AG Series, 120/240 VAC Electrical Rating, 50/60 Hz Frequency, 3 Pole, 20 kA Short Circuit, 10 kA Nominal Discharge, Modes of Protection: L-N/L-L, Green LED Indicator, 1 ph, Environmental Conditions: -13 to 140 deg F Operating Temperature, NEMA 1/2/4X Enclosure, Surface Mounting, Lead Terminal, Polycarbonate, 1/2 in H Dimensions
- DEVICE PROT SRG 120/240VAC 50/60HZ
- Product Catalog Page(s)
Specification Sheet
- CSA-UL 1449 3rd Edtion
- Brand: IntermaticApplication: HVAC Equipment (AC/Furnaces)Connection: 18 IN LeadCountry of Origin: MXEnvironmental Conditions: -4 to +104 DEG F, -20 to +40 DEG CFrequency Rating: 50/60 HzInsulation: UL Rated Plastic 94V-0Material: PolycarbonateMounting: 10 Gauge Wire LeadOperating Temperature: -13 to +140 DEG F, -25 to +60 DEG CPhase: SingleShort Circuit Rating: 20 KAMPSize: 1/2 IN - 20Special Features: Features: LED Indicator provides Status; UV ResistantStandard: CSA - UL 1449 3rd EdtionType: Type 1/Type 2 Surge Protective DeviceType Of Indicators: Green LEDVoltage Rating: 120/240
