MILB U7487-RL-TG-KK-BLG
MFG #U7487-RL-TG-KK-BLG
UPC #78457224177
SKU #3769236
16 in Stock
Stock Item
More available 08/25/2026
$161.48/EA
Product description
MILB U7487-RL-TG-KK-BLG 125AMP (1)POSITION (4)TERMINAL OVERHEAD HORN BY-PASS RINGLESS BARREL LOCK TRIPLEX GROUND ALLEGHANY -GPU -PPL APPROVED
Milbank® Meter Socket, Ringless, 600 VAC, 125 A, 1 ph, 60 Hz Frequency, Overhead/Underground Feed, Line/Load Terminal, Surface Mounting, NEMA 3R Enclosure
Milbank® Meter Socket, Ringless, 600 VAC, 125 A, 1 ph, 60 Hz Frequency, Overhead/Underground Feed, Line/Load Terminal, Surface Mounting, NEMA 3R Enclosure
- Milbank® Meter Socket, Ringless, 600 VAC, 125 A, 1 ph, 60 Hz Frequency, Overhead/Underground Feed, Line/Load Terminal, Surface Mounting, NEMA 3R Enclosure
- SOCKET MTR 600VAC 125A 1 NEMA 3R 60HZ
- Product Catalog Page(s)
Specification Sheet
- UL Listed
- Brand: MilbankAmperage Rating: 125 Continuous AmpereApplication: Meter SocketBypass Type: Horn BypassCable Entry: Overhead or UndergroundCountry of Origin: USACutout Size: No Main BreakerEnclosure: G90 Galvanized Steel with Powder Coat FinishEquipment Ground: Triplex GroundFrequency Rating: 60 HertzHub Opening: Small Hub OpeningInsulation: Glass PolyesterJaw Quantity: 4 TerminalLine Side Wire Range: 6 - 2/0 AWGLoad Side Wire Range: 6 - 2/0 AWGMounting: Surface MountNumber of Cutouts: 0Number of Meter Positions: 1 PositionPhase: 1 PhaseSize: 3.313L x 8W x 11.5HSpecial Features: 4 Terminal, Small Hub Opening, Triplex Ground, Horn Bypass, 7/8 Inch Knockout and Angle Bracket for Barrel Lock Provision, 1 PositionStandard: UL Listed;Type 3RTerminal: Lay inType: Ringless Meter SocketVoltage Rating: 600 Volts Alternating Current
