GEDI TG3222R
MFG #TG3222R
UPC #78316400850
SKU #284813
Product description
GE TG3222R 60AMP 240VAC 2POLE 3WIRE FUSED NEMA3R GENERAL DUTY SAFETY SWITCH
GE Spec-Setterâ„¢ Safety Switch, Fusible General Duty, Series: TG Series, 240 VAC, 60 A, 3 hp Standard Fuse/10 hp Time Delay, 1 ph, 50/60 Hz Frequency, 2 Pole, 3 Wires, 100 kA Short Circuit, Handle Actuator, NEMA 3R Enclosure, Surface Mounting, 60/75 deg C, 13.68 in H x 8.4 in W x 3.9 in D Dimensions, Steel
GE Spec-Setterâ„¢ Safety Switch, Fusible General Duty, Series: TG Series, 240 VAC, 60 A, 3 hp Standard Fuse/10 hp Time Delay, 1 ph, 50/60 Hz Frequency, 2 Pole, 3 Wires, 100 kA Short Circuit, Handle Actuator, NEMA 3R Enclosure, Surface Mounting, 60/75 deg C, 13.68 in H x 8.4 in W x 3.9 in D Dimensions, Steel
- Residential, Light Commercial, Electrical Distribution and Control Applications
- GE Spec-Setter™ Safety Switch, Fusible General Duty, Series: TG Series, 240 VAC, 60 A, 3 hp Standard Fuse/10 hp Time Delay, 1, 50/60 Hz, 2 Pole, 3 Wires, 100 kA Short Circuit, Handle Actuator, NEMA 3R, Surface Mount, 60/75 deg C, 13.68 in H x 8.4 in W x 3.9 in D, Steel
- Self-leveling, 3-point mounting system
Integral cover interlock
Visible confirmation of plated blade contact positions
Spring reinforced fuse clips assure reliable contact for cool operation
Suitable for class H, K, J or R fuses, where applicable
UL listed short circuit rating is 10000 rms symmetrical amps standard
With class R fuses and fuse kits installed, 30 to 200 A switches have UL listed short circuit rating of 100000 rms symmetrical A
UL listed as service entrance equipment when installed in accordance with the national electric code
- SWITCH SAF 240VAC 60A 2 1 50/60HZ 3 HDL
- Product Catalog Page(s)
Specification Sheet
- ARRA Compliant|Buy American Act Compliant|RoHS Compliant|UL 98|CSA C22.2 No. 4-04|cUL Listed|Federal Specification WS-865C|NEMA KS1-2013|Seismic Certified
- Brand: Industrial Conn & Solutions (GE)Amperage Rating: 60AApplication: GeneralCountry of Origin: UKNEnclosure: NEMA 3R (Outdoor)Number of Poles: 2Size: 13.68 inStandard: UL 98|CSA C22.2 No. 4-04|cUL Listed|Federal Specification WS-865C|NEMA KS1-2013|Seismic CertifiedSub Brand: GE Industrial SolutionType: Safety switchVoltage Rating: 240 VAC
