GEDI TGN3321
MFG #TGN3321
SKU #3758333
$105.58 per EA (1) / EA
16 in Stock. More available 05/15/2024
Stock Item
Product description
GE TGN3321 30AMP 240VAC 3POLE 3WIRE NON-FUSED NEMA1 GENERAL DUTY SAFETY SWITCH
Designed for residential and light commercial applications where duty is not severe. Listed to UL standard 98 enclosed and dead front switches. Suitable for use as service equipment when installed in accordance with the National Electrical Code. Certified to CSA standard 22.2 no. 4-04 enclosed and dead front switches. Meets or exceeds NEMA KS1 standard for enclosed switches, type GD. Fusible and non-fusible switches available (consult BuyLog for interrupt ratings). Quick-make, quick-break mechanism (30-200 amp). 60/75 C conductor rating. TGN38784
Designed for residential and light commercial applications where duty is not severe. Listed to UL standard 98 enclosed and dead front switches. Suitable for use as service equipment when installed in accordance with the National Electrical Code. Certified to CSA standard 22.2 no. 4-04 enclosed and dead front switches. Meets or exceeds NEMA KS1 standard for enclosed switches, type GD. Fusible and non-fusible switches available (consult BuyLog for interrupt ratings). Quick-make, quick-break mechanism (30-200 amp). 60/75 C conductor rating. TGN38784
- Residential, Light Commercial, Electrical Distribution and Control Applications
- Designed for residential and light commercial applications where duty is not severe. Listed to UL standard 98 enclosed and dead front switches. Suitable for use as service equipment when installed in accordance with the National Electrical Code. Certified to CSA standard 22.2 no. 4-04 enclosed and dead front switches. Meets or exceeds NEMA KS1 standard for enclosed switches, type GD. Fusible and non-fusible switches available (consult BuyLog for interrupt ratings). Quick-make, quick-break mechanism (30-200 amp). 60/75 C conductor rating. TGN38784
- Self-leveling, 3-point mounting system
Integral cover interlock
Visible confirmation of plated blade contact positions
Spring reinforced fuse clips assure reliable contact for cool operation
Suitable for class H, K, J or R fuses, where applicable
UL listed short circuit rating is 10000 rms symmetrical amps standard
With class R fuses and fuse kits installed, 30 to 200 A switches have UL listed short circuit rating of 100000 rms symmetrical A
UL listed as service entrance equipment when installed in accordance with the national electric code
- 30A 3P GD N1 240V NONFUSE SWITCH
- Product Catalog Page(s)
Specification Sheet
- ARRA Compliant|Buy American Act Compliant|RoHS Compliant|UL 98|CSA C22.2 No. 4-04|cUL Listed|Federal Specification WS-865C|NEMA KS1-2013|Seismic Certified
- Brand: Industrial Conn & Solutions (GE)Amperage Rating: 30AApplication: GeneralCountry of Origin: UKNEnclosure: NEMA 1 (Indoor)Number of Poles: 3Size: 10.28Standard: YesSub Brand: GE Industrial SolutionType: Safety switchVoltage Rating: 240 VACIDW2 Image1 URL: https://ideadigitalasset.com/DAMRoot/Original/11318/10985_U5L9C0MVOQ4Y2HDP.jpg
