Schaedler Yesco | AB 1492-L3Q-B

AB 1492-L3Q-B

MFG #1492-L3Q-B

SKU #2920496

CALL FOR PRICE

QTY

U/M

AB 1492-L3Q-B #30-#12AWG 600VAC/DC BLUE FEED THROUGH TERMINAL BLOCK W/(2) CONNECTION POINTS ON EACH SIDE SPRING CLAMP CONNECTIONS

: Specification Sheet
: Brand: AB Industrial Control
Amperage Rating: 21/24/25/27 A, R - 25A, CSA - 27A, IEC -24A, ATEX - 21A
Color: Blue, lue
Country of Origin: DE
Special Features: Spring Clamp Connection, Feed Through with 3 Connection Points 2 on One Side, 1 Pole, Blue, Pkg. Qty. of 100, pring Clamp Connection, FeedThrough with 3 ConnectionPoints 2 on One Side, 1 Pole,Blue, Pkg. Qty. of 100
Standard: CCC, CE, CSA, CUL, KC, MARINE, UL
Sub Brand: 1492
Terminal Size: .1 x 79 x 31.3mm (0.20 x 3.11x 1.23 in), 5.1 x 79 x 31.3mm (0.20 x 3.11 x 1.23 in)
Type: EC Spring Clamp TerminalBlock, IEC Spring Clamp Terminal Block
Voltage Rating: 550/600/800//550/600/800 VAC//VDC, R - 600V AC/DC, CSA - 600VAC/DC, IEC - 800V AC/DC, ATEX- 550V AC/DC
Wire Size: R - #30...12 AWG, CSA -#26...12 AWG, IEC - 2.5mm²,ATEX - #20...12 AWG, UR - #30...12 AWG, CSA - #26...12 AWG, IEC - 2.5mm², ATEX - #20...12 AWG
