GEDI 9T10A1004
MFG #9T10A1004
UPC #78317390449
SKU #4079900
Product description
GE 9T10A1004 AL 75KVA 480-208Y 150C K1 STD DOE 2016
GE General Purpose Transformer, Type QL Dry Type, 480 VAC Primary, 208Y/120 VAC Secondary, 75 kVA Power, 60 Hz Frequency, 3 ph, 7 Taps, Lug Connection, Flange Mounting, NEMA 2 Enclosure, 40 deg C, 35.7 in H x 31.8 in W x 24 in D Dimensions
GE General Purpose Transformer, Type QL Dry Type, 480 VAC Primary, 208Y/120 VAC Secondary, 75 kVA Power, 60 Hz Frequency, 3 ph, 7 Taps, Lug Connection, Flange Mounting, NEMA 2 Enclosure, 40 deg C, 35.7 in H x 31.8 in W x 24 in D Dimensions
- Commercial, Industrial, Motors, Incandescent Lighting, Resistance Heating and Motor Generator Applications
- GE Type QL transformers meet DOE 2016 efficiency standards. They are available with aluminum or copper windings and utilize a UL recognized 220 degree centrigrade insulation system.-Quiet Performance-Outward-facing mounting feet-Lug kit included-Ground bar kit included-Core and coil assemblies are mounted on rubber isolation pads to reduce noise-Bolted coil terminations-Single-piece front/back is easily removable for service-NEMA 2 drip-proof enclosure is standard weathershield kits are available for conversion to NEMA 3R outdoor configuration-Qualified to the seismic requirements of IEEE-693-2005 and IBC-2012 and CBC 2013-Copper or aluminum windings-Copper ground strap-Robust packaging with top and side protection protects against shipping damage-Accessible mounting flanges with front/back slotted mounting holes make installation easier-100 percentage factory tested for shorts and coil integrity, current and loss, voltage, impedance and noise.-Clear, comprehensive documentation and labeling 10A1004
- 75KVA 3P AL 480-208Y/120 150C DOE
- Product Catalog Page(s)
Specification Sheet
- ARRA Compliant|Buy American Act Compliant|RoHS Compliant|ASCE 7.05|CBC-2013|IEEE-693-2005|IBC-1012|UL Listed|DOE 2016
- Brand: Industrial Conn & Solutions (GE)Application: Electrical distribution and ControlCountry of Origin: UKNEfficiency: DOE 2016Enclosure: NEMA 2Frequency Rating: 60 HzKVA Rating: 75Phase: 3Primary Voltage: 480Secondary Voltage: 208Y/120Standard: ASCE 7.05|CBC-2013|IEEE-693-2005|IBC-1012|UL Listed|DOE 2016Sub Brand: GE Industrial SolutionTemperature Rating: 40 ?°CType: Distribution power transformers
