LEV 8430
MFG #8430
UPC #07847784330
SKU #3928819
1 in Stock
Stock Item
More available 05/20/2026
$98.25/EA
Product description
LEV 8430 IND/30A 4 WIRE RECEPT
Leviton®, 8430, Grounding Straight Blade Power Receptacle, Extra Heavy Duty, 250 VAC, 30 A, 3 hp, 3 Pole, 4 Wires, NEMA 15-30R NEMA Rating, Commercial/Industrial Grade, -40 to 60 deg C, Side Wire Terminal, Thermoplastic, Black, 3.75 in H x 2.5 in W x 2.1 in D Dimensions
Leviton®, 8430, Grounding Straight Blade Power Receptacle, Extra Heavy Duty, 250 VAC, 30 A, 3 hp, 3 Pole, 4 Wires, NEMA 15-30R NEMA Rating, Commercial/Industrial Grade, -40 to 60 deg C, Side Wire Terminal, Thermoplastic, Black, 3.75 in H x 2.5 in W x 2.1 in D Dimensions
- Factories, Schools, Hospitals and Commercial Office Buildings
- Leviton®, 8430, Grounding Straight Blade Power Receptacle, Extra Heavy Duty, 250 VAC, 30 A, 3 hp, 3 Pole, 4 Wires, NEMA 15-30R NEMA Rating, Commercial/Industrial Grade, -40 to 60 deg C, Side Wire Terminal, Thermoplastic, Black, 3.75 in H x 2.5 in W x 2.1 in D Dimensions
- RECEPTACLE PWR BL STR 250VAC 30A 3 4 BK
- Product Catalog Page(s)
MSDS
Specification Sheet
- NEMA WD1/WD6|ANSI C73|NOM 057|CSA C22.2 No. 42 File No. 152105|UL 498 File No. E13399/E13393|UL94 V-2 Flammability Rating
- Brand: LevitonAmperage Rating: 30 AMPApplication: CommercialColor: BlackConnection: Side WiredCountry of Origin: MXDielectric Strength: 2000 (Min.)Environmental Conditions: Flammability (Rated V-2 per UL94)Material: ThermoplasticMounting: BoxNEMA Rating: 15-30RNumber of Poles: 3Number Of Wires: 4Phase: 3Size: 3.75 H x 2.50 W x 2.10 D INSpecial Features: Industrial Grade, GroundingStandard: NEMA (WD-1, WD-6);ANSI (C-73);NOM Certified (057);CSA C22.2 No. 42 (File 152105);UL Listed 498 (File E13399, File E13393)Temperature Rating: -40 to +60 DEG CType: Power ReceptacleVoltage Rating: 250Wire Size: 14-6
