Schaedler Yesco | PS 1597-GRY

PS 1597-GRY

MFG #1597-GRY

UPC #78500703584

SKU #4115372

QTY

Product description

PS 1597-GRY SELF-TEST GFCI RECEP 15A 125V 20A F GY
Pass & SeymourÂ® RadiantÂ® GFCI Receptacle, Duplex Self-Test, Series: 1597, 125 VAC, 15 A, 1/2 hp, 60 Hz Frequency, 2 Pole, 3 Wires, NEMA 5-15R NEMA Rating, Residential/Specification Grade, -35 to 66 deg C, Back/Side Wire Terminal, Thermoplastic, Gray, 1.03 in L x 1.73 in W x 4.2 in H Dimensions

: Industrial, Health Care, Education, Institutional, Retail, Office, Hospitality/Lodging and Multiple Dwelling, Commercial and Residential Applications
: Pass & SeymourÂ® RadiantÂ® GFCI Receptacle, Duplex Self-Test, Series: 1597, 125 VAC, 15 A, 1/2 hp, 60 Hz Frequency, 2 Pole, 3 Wires, NEMA 5-15R NEMA Rating, Residential/Specification Grade, -35 to 66 deg C, Back/Side Wire Terminal, Thermoplastic, Gray, 1.03 in L x 1.73 in W x 4.2 in H Dimensions
: RECEPTACLE GFCI 125VAC 15A 2 3 GRA
: Product Catalog Page(s)
Specification Sheet
: CSA C22.2 No. 42/144|cULus Listed File No. E42190|Federal Specification W-C-596|FULs Listed|UL 943|UL 94 V-2 Flammability Rated
: Brand: Pass & Seymour Legrand
Actuator: Control Circuit
Amperage Rating: 15
Application: Commercial/Residential
Connection: Back and side wire
Country of Origin: CN
Environmental Conditions: 95% Humidity, UL 94 V2
Frequency Rating: 60 Hz
Height: 4.2
Interrupt Rating: 4 to 6 mA
Length: 1.03
Material: Thermoplatic
NEMA Rating: 15A
Number of Poles: 2
Operating Temperature: -35°C to +66°C
Special Features: Spec Grade
Standard: CSA C22.2 No. 42/144|cULus Listed File No. E42190|Federal Specification W-C-596|FULs Listed|UL 943|UL 94 V-2 Flammability Rated, CULUS, UL, cULus, UL Listed, FSUL
Sub Brand: Pass & Seymour, radiant
Trip Range: 4 to 6 mA
Trip Type: .025 Second Nominal
Type: Outlet, Specification Grade 15A Self-Test Duplex GFCI
Voltage Rating: 125
Width: 1.73
