TB 60178
MFG #60178
UPC #78621060178
SKU #1582358
Product description
TB 60178 #750MCM 5/8" BOLT HOLE COMPRESSION LUG DIE CODE YELLOW ALUMINUM/COPPER
Color-Keyed® Compression Connector Lug, 1-Hole, Aluminum/Copper Conductor, 750 kcmil Conductor, Die Code: 115H, 35 kV, 5/8 in Stud, Straight Tongue, 2 in L x 2.13 in W x 0.4 in THK Tongue, 6.03 in Overall Length, Blind End/Long Barrel, 1-1/2 in Dia Barrel, 90 deg C, Aluminum, Yellow
Color-Keyed® Compression Connector Lug, 1-Hole, Aluminum/Copper Conductor, 750 kcmil Conductor, Die Code: 115H, 35 kV, 5/8 in Stud, Straight Tongue, 2 in L x 2.13 in W x 0.4 in THK Tongue, 6.03 in Overall Length, Blind End/Long Barrel, 1-1/2 in Dia Barrel, 90 deg C, Aluminum, Yellow
- Color-Keyed® Compression Connector Lug, 1-Hole, Aluminum/Copper Conductor, 750 kcmil Conductor, Die Code: 115H, 35 kV, 5/8 in Stud, Straight Tongue, 2 in L x 2.13 in W x 0.4 in THK Tongue, 6.03 in Overall Length, Blind End/Long Barrel, 1-1/2 in Dia Barrel, 90 deg C, Aluminum, Yellow
- Easily matched to the correct Color-Keyed® installing die for positive compressions
Hardened steel dies compress connector around cable, changing round strands to polygonal shapes and cold flowing strands and connector into a solid, homogenous mass
Long compression areas ensure complete contact
Multiple compressions prevent creep of aluminum conductors
Filled with high temperature oxide inhibiting compound
Electro-tin plating prevents electrolytic corrosion of copper to ensure lowest contact resistance
High conductivity wrought aluminum construction
- LUG CONNECTOR COMPRESSION 750KCMIL 115H
- Product Catalog Page(s)
MSDS
Specification Sheet
- CSA Certified|UL File No. E9809
- Brand: Thomas & BettsCable Size: 750 kcmilColor: YellowCountry of Origin: MXInsulation: NoneMaterial: AluminumNumber of Holes: 1Standard: UL E9809 / UL E9809Stud Size: 5/8 inSub Brand: Color KeyedType: Long BarrelVoltage Rating: 35 kV
