TB 60275
MFG #60275
SKU #302683
$5921.80 per C (100) / EA
23 in Stock. More available 05/10/2024
Stock Item
Product description
TB 60275 #600MCM (2)1/2" BOLT HOLES COMPRESSION LUG 1.75" SPREAD DIE CODE BLACK ALUMINUM/COPPER
Color-Keyed Compression Lug, 2-Hole Non-Insulated, Aluminum/Copper Conductor, 600 kcmil Conductor, Die Code: 106H, 35 kV, 1/2 in Stud, Straight Tongue, 3 in L x 1.92 in W x 0.37 in THK Tongue, 6.83 in Overall Length, Blind End/Long Barrel, 1.36 in Dia Barrel, Specifications: 1-3/4 in Stud Hole Spacing, Tin Plated, 90 deg C, Aluminum, Black
Color-Keyed Compression Lug, 2-Hole Non-Insulated, Aluminum/Copper Conductor, 600 kcmil Conductor, Die Code: 106H, 35 kV, 1/2 in Stud, Straight Tongue, 3 in L x 1.92 in W x 0.37 in THK Tongue, 6.83 in Overall Length, Blind End/Long Barrel, 1.36 in Dia Barrel, Specifications: 1-3/4 in Stud Hole Spacing, Tin Plated, 90 deg C, Aluminum, Black
- Color-Keyed Compression Lug, 2-Hole Non-Insulated, Aluminum/Copper Conductor, 600 kcmil Conductor, Die Code: 106H, 35 kV, 1/2 in Stud, Straight Tongue, 3 in L x 1.92 in W x 0.37 in THK Tongue, 6.83 in Overall Length, Blind End/Long Barrel, 1.36 in Dia Barrel, Specifications: 1-3/4 in Stud Hole Spacing, Tin Plated, 90 deg C, Aluminum, Black
- For aluminum and copper concentric conductors and compact code aluminum strands
Filled with oxide inhibitor compound
High conductivity wrought aluminum construction
Tin plated finish
- LUG COMPRESSION 600KCMIL AL/COPPER 106H
- Product Catalog Page(s)
MSDS
Specification Sheet
- CSA Certified|UL File No. E9809
- Brand: Thomas & BettsCable Size: 600 KCMILColor: BlackCountry of Origin: MXInsulation: NoneMaterial: AluminumNumber of Holes: 2Standard: UL E9809Stud Size: 1/2 inSub Brand: Color KeyedType: Long BarrelVoltage Rating: 35 kVIDW2 Image1 URL: https://ideadigitalasset.com/DAMRoot/Original/12199/12055_WRPU8KSXMAITG3Y1.jpg
